The Wallenstein WP1624 is the latest addition to our range of firewood processors. A highly capable and mobile wood processor, this machine is great value for money and built in Canada.
- Powerful 747cc Kohler CH752 petrol engine
- Three hydraulic pumps mounted in-line
- 20T split force
- Maximum log diameter 460mm
- Folding two-stage live deck, 1800mm wide
- .404 18HX Harvester chain
- Auto bar oiler
- Wallenstein's proprietary P3 Pulse load sensing technology guides the bar through the timber without jamming
- Hydraulic gear motor bar motor
- Maximum production of 12.6m3 /hr
Specifications
- Product Code: WP1624-12
- Engine: Briggs & Stratton 29Hp Vanguard, 896cc
- Pump: 14gpm Stage 1 / 7.75gpm Stage 2 / 4.15gpm Stage 3
- Cut-to-Cut Cycle Time: 12 Seconds Return
- Stroke Length: 26" / 660mm
- Ram Size: 4"
- Splitting Force: 20Ton
- Max Log Diameter: 18" (460mm)
- Knife: Adjustable 4-Way
- Max Discharge Chute Height: 1900mm
- Wheels: 5.30x12" with Torflex Suspension
- Folded Length: 5890mm
- Folded Width: 1670mm
- Folded Height: 2660mm
- Overall Length: 5890mm
- Overall Width: 2890mm
- Overall Height: 1930mm
- Weight: 1450kg
- Conveyor: 12ft integrated
- Production Capacity: 12.6m3/hr
Warranty
Wallenstein guarantees it to be free of defects in materials and workmanship under normal use for:
- 5 Years Domestic use
- 2 Years Commercial use
- Warranty is void if machine is modified
